Hospital Hermetic Door
1. The operating system adopts modular design, maintenance-free driver, high-efficiency motor, and micro chip, which effectively guarantees excellent performance and strong driving force for the sliding doors.
2. . It requires less valuable space, when operated produce less air disturbance making them ideal for environment.
3. The pressure moulded smooth seamless construction is easy to clean, does not harbour bacteria. Sliding operating doors are extremely strong and durable, yet light and easy to operate.
4. Versatile open options: Overhead sensors, button-press system, foot sensors ,fingerprint system
5.The door is aluminum framed with double-glazed glass window
6. There is light probe attached to door frame for the sake of safety
- Product details
Product parameters
Product parametersProduct features:
1. Adopt DC brushless motor as its driving core, which can be opened single or double.
2. There are plug-in and embedded installation, keeping the same plane with the wall, more beautiful and full of sense.
3. The opening and closing are stable, convenient, safe and reliable, and can meet the special requirements of air tightness, sound insulation and intelligence.
4. Rubber sealing is installed on each side of the door leaf to fill the gap between the door leaf and the door frame. The airtight performance is excellent. It can prevent dust and bacteria and reduce air leakage, ensuring the gradient distribution of the air pressure difference between adjacent rooms. The role.
5. The door leaf is surrounded by an aluminum-gold frame structure. The surface is made of brushed stainless steel panel or high-quality electrostatic sprayed high-quality aluminum alloy panel or aluminum-plastic plate or galvanized steel plate. A variety of spray-painted colors and anti-Bate plates are available.
6. The center of the door is filled with paper honeycomb aluminum honeycomb (with flame retardant), with 5mm thick tempered double-layer hollow glass.
7. The door frame and the wall keep the same plane, which is more beautiful and full of sense. The sealing strip is installed in three weeks, and the sweeping strip is installed at the bottom of the door body, which meets the hygienic requirements of various industries.
1. Adopt DC brushless motor as its driving core, which can be opened single or double.
2. There are plug-in and embedded installation, keeping the same plane with the wall, more beautiful and full of sense.
3. The opening and closing are stable, convenient, safe and reliable, and can meet the special requirements of air tightness, sound insulation and intelligence.
4. Rubber sealing is installed on each side of the door leaf to fill the gap between the door leaf and the door frame. The airtight performance is excellent. It can prevent dust and bacteria and reduce air leakage, ensuring the gradient distribution of the air pressure difference between adjacent rooms. The role.
5. The door leaf is surrounded by an aluminum-gold frame structure. The surface is made of brushed stainless steel panel or high-quality electrostatic sprayed high-quality aluminum alloy panel or aluminum-plastic plate or galvanized steel plate. A variety of spray-painted colors and anti-Bate plates are available.
6. The center of the door is filled with paper honeycomb aluminum honeycomb (with flame retardant), with 5mm thick tempered double-layer hollow glass.
7. The door frame and the wall keep the same plane, which is more beautiful and full of sense. The sealing strip is installed in three weeks, and the sweeping strip is installed at the bottom of the door body, which meets the hygienic requirements of various industries.
| Door leaf weight | 150KG |
| Door width | Single door ≤2000mm Double door ≤3000mm |
| Doorway height | 2100mm-3000mm |
| Opening speed | 250-500mm / s (adjustable) |
| Closed door running speed | 250-500mm / s (adjustable) |
| Development time | 2-20s (adjustable) |
| Tightening force F | ＞ 70N |
| Manual thrust | ＜ 100N |
| Overall power consumption | ＜ 150W |
